ELECSOUND is a professional PCB manufactor with 10 years' export experience. Located in Shenzhen, China.
We have skilled and professinal staffs for production line. We can supply FR-4, metal core aluminum based, polyimide, etc. Our PCB factory has obtained ISO 9001 and UL, and we specialize in single, double-sided, 4 layer to 8 layers at a very competitive price with excellent quality. Lead time is 7 to 10 days only.
We produced custom PCBs as below:
Single-sided PCB,
double-sided PCB,
4 layers PCB, and multilayer PCB.
We provide different surface finished as customized, such as: HASL lead free, ENIG, hard gold plating, OSP, Rosin, etc.
Files format available as below:
CAM350 Gerber file,
Protel 99 SE
Printed Circuit Board Customized Manufacturing according to Gerber Files or original source file
| Content | Capability | |||||||
| Material | FR4, TG130, TG140, TG160, TG170 | |||||||
| Surface treatment | HASL,Chemical Tin,ENIG(Immersion GOLD),OSP,IMT,Plating silver, GOLD Finger | |||||||
| Layers | Single-sided,double-sided,4 layers, 6,8,10,12 Layers | |||||||
| Maxi. board size | 800mmX508mm | |||||||
| Line width/space | 0.1mm/ 0.1mm | |||||||
| Board thickness | 0.2mm-4mm | |||||||
| Min.tolerance of Board thickness | +/-8% - 10% | |||||||
| Copper foil thickness | Out Layer: 17.5um/35um/70um/105um/140um/175um Inner Layer: 17.5um/35um/70um/105um/140um | |||||||
| Outline Tolerance | CNC routing:+/-0.1mm , Punching: +/-0.1mm | |||||||
| V-CUT registration | +/-0.15mm | |||||||
| PTH hole copper thickness | 15um-50um | |||||||
| Warp and twist | <=1% | |||||||
| Min. registration of hole position | +/-3mil(+/-0.76mm) | |||||||
| Min.punching hole | 0.8mm(Board thickness below 1.0mm .) | |||||||
| Min.Punching Square slot | (Board thickness below 1.0mm, 1.0mmX1.0mm) | |||||||
| Registration of printed circuit | +/-0.076mm | |||||||
| Min.drill hole diameter | 0.2mm | |||||||
| Min.tolerance of hole diameter | +/-0.05mm | |||||||
| Thickness of surface treatment | Plating Gold:(Ni4um-6um ,Au 0.1um-0.5um), Immersion GOLD: (Ni 5um-6um,Au:0.0254um-0.127um), Plating Silver:(Ag 5um-8um) | |||||||
| V-CUT degree tolerance | +/-5(degree) | |||||||
| V-CUT Board thickness | 0.6mm-3.2mm | |||||||
| Min.Legend width | 0.1mm | |||||||
| Min.Solder mask width | 0.1mm | |||||||
| Min.Solder mask ring | 0.05mm | |||||||
