Multifunctional Resistance Spot Welder Description:The spot welder features: easy maneuverability, simple operation and high output power. The welder can be used for a wide variety of applications, such as dent pulling, carbon heating and shrinking, single-sided spot welding, stud bolt welding, sheet plate cutting and sheet

Featured Products

Multifunctional Resistance Spot Welder



Description:
The spot welder features: easy maneuverability, simple operation and high output power. The welder can be used for a wide variety of applications, such as dent pulling, carbon heating and shrinking, single-sided spot welding, stud bolt welding, sheet plate cutting and sheet metal welding. Using this versatile welder in body repair work, panels will need to be replaced less frequently and repair jobs will be completed in a shorter space of time.

Features:
The microprocessor control system optimizes the welding parameters. Using advanced digital control technology and user friendly design, all you have to do is select the welding current corresponding to the work piece thickness to achieve the best welding results.
High precision time adjustment system
Automatic mains voltage monitoring
A welding gun test function to evaluate the usage status of the welder
Overheating protection
A variety of welding procedures are available such as shrinking, washer, direct-pulling, spot welding, flattening, waveform wire, stud welding, OT washer and triangle washer
Digital display
Equipped with changeable spot gun and multi-functional puller
Adjustable welding current
Complete with pneumatic vacuum cupule

Specifications:
Model FY8000
Input voltage:
Input power:
Input current:
Max welding current:
Output voltage carbon rod heating:
Output voltage washer melting rate:
Output voltage butt-weld:
One-side welding thickness:
Operation way:
Weld timing range:
Weld current regulation:
Cable length:
Dimensions:
Weight:
220V or 380V 50/60Hz
21KVA
55A
5400A
AC6-10V
AC1-12V
AC1-13V
0.8+1.2mm
continuity
0-99s
ABC
2300+1900mm
620*450*980mm
80kg



The features of BH8000/BH7000 digital car body dent pulling machine are high output power,easy to move and simple to operate.The welder is used for a wide variety of applications,such as dent pulling,carbon heating and shrinking,single-sided spot welding,stud bolt welding,sheet plate cutting and sheet metal welding.Use this versatile welder in body repair work,you will need less replacement of panels and less time to finish your work.It will changer the way you work entirely.

Accessories:


NO.AccessoriesFY8000
NO.F001Pneumatic vacum Cuple1set
NO.F002pulling hammer with hook1set
NO.F003Dent pulling spot hammer1set
NO.F006wavy wire15pcs
NO.F007carbon rod5pcs
NO.F008Spot welding electrode tip1pc
NO.F009carbon rod connector1pc
NO.F0010wavy wire electrode tip1pc
NO.F0011washer connector1pc
NO.F0014Claw1pc
NO.F0015Triangle washer10pcs
NO.F0016Stud30pcs
NO.F0017φ12mm Washer15pcs
NO.F0017φ10mm washer15pcs
NO.F0018Earth clamp1pc
NO.F0019Manual Cupule --
NO.F0030OT easher20pcs
NO.F0033Wrench1pc
NO.F0034Stud connector1pc
